This project aims to establish an internal power collection network to ensure the stable aggregation and transmission of electricity for the ANMA Offshore Wind Farm, located in the offshore area near Anma Island along the western coast of Jeollanam-do, Republic of Korea. Electricity generated by the offshore wind turbines will be reliably transmitted to the offshore substation through a well-designed internal collection system. To this end, rational and reliable design criteria for the wind farm’s internal collection system, namely the Inter-Array Cables (IACs), are to be established.

BANDI has carried out the design of the internal collection cables (IACs) for this project. The scope of work includes defining cable routes, layouts, and design conditions through a comprehensive consideration of offshore environmental conditions, seabed topography and geotechnical characteristics, constructability, and operational reliability. The ultimate objective is to secure the long-term operational reliability of the collection system and to contribute to the stable operation of the overall wind farm electrical network.

The general tasks to be performed under this scope are as follows:

- Definition of IAC design input conditions considering offshore environmental characteristics

- Optimization of IAC routing and configuration based on wind farm layout

- Application of cable installation and protection concepts reflecting seabed and geotechnical conditions

- Application of IAC design criteria in compliance with international standards

- Design of the collection system considering operation and maintenance requirements

Detailed Scope of Work

- Part I – Technical Support for Vertical Injector Engineering

• Coordinating with Vuyk up to the contract award stage (conceptual and detailed design phases)

• Review of the feasibility study prepared by a European consulting company

• Motion analysis of cable-laying vessels

• Structural and stability assessment of cable-laying vessels

• Coordination with the client on matters including the DNV certification

schedule

• Coordination with vessel owners regarding the installation of the Vertical Injector

• Coordinating with classification societies (DNV, KR, etc.) in relation to Marine Warranty Surveyor (MWS) activities

• Contract period: October 2025 – June 2026 (8 months)

- Part II – Engineering Support for Subsea Cable Installation Procurement

• Engineering support for cable accessories and hang-off systems

• Collaboration on the selection of Crew Transfer Vessels (CTV)

• Support related to ROVs (Remotely Operated Vehicles) for trenching operations

• Collaboration on the selection of accommodation barges

• Contract period: October 2025 – July 2027 (21 months)

- Part III – Basic Design Review and Detailed Design

• Contract period: January 2026 – December 2026 (12 months)

- Part IV – Construction Engineering for Subsea Cable Installation

• Contract period: July 2027 – August 2028 (13 months)
